Categories
design

Fun with Ekahau 3D design

Heritage building at University of Milan, Italy

Floor plans in Ekahau Pro designs are strictly 2D. Tri-dimensional features can be added using wall height, AP height and ceiling height in a building artifact, which is basically a stack of floor plans scaled and aligned vertically. In a building, the hole in floor is a powerful tool to render complex features such as balconies, staggered floors, stairwells, courtyards and shafts. Despite all this 3D features, floor plans are strictly horizontal, and cannot represent inclined surfaces, slopes or stadium tiers.

I had to design wi-fi for a small lecture hall recently, and thought I could have some fun stretching Ekahau 3D concepts to the limit and learning something new.

The lecture hall was built in the 1920s with a steep auditorium design that enabled attendees to hear and see the podium without any audio/video technology, even from the farthest seat. It has 13 rows of seats on a stepped floor, each step 40cm high.

Auditorium, front, back and side section view

To simulate the stepped floor I planned a building with 14 identical floor plans (one for each seat row), each floor with 40 cm ceiling height. Using holes in floor I then planned to cut out every floor leaving only the step area, and placing a 40 cm high wall on the step rise.

Lesson learned 1: the minimum ceiling height in Ekahau Pro is 1m. I had to simplify the design by grouping the steps and reducing the building from 14 to 7 floors.

Using the hole in floor tool I cut out the floors, placed a custom 1m high wall to simulate the step rise, and added areas and attenuation areas on the active surfaces on each level.

I placed a simulated AP in floor 1 at 4m height and displayed the signal strength at every seat row. Lesson learned 2: even if the ceiling is 1m, the software allows placing an AP higher, regardless of floors above.

At first, the predictive design did not display the RF signal on the all the floors. Lesson learned 3: enable Signal prediction: all floors on the Options button. Please also note that the default visualization height is 1m from the floor, this can be customized with Ctrl+Options.

Playing with the AP position and height allows to explore the different attenuation effects in 3D space. It is an approximation to the real shape of the hall, and of the RF attenuation effects, as good as the Ekahau software goes.

Here is an example of predictive signal strength in 5Ghz, where the attenuation from areas, floors and walls is clearly visible. Besides signal strength, all the usual visualizations are possible; my other favorites are Capacity and Health.

This technique is fun, but unless there are very specific requirements in designated areas, this kind of auditorium design is an overkill in real life. During surveys, this design would force switching floor plan every few meters. Viewing survey data would also be unpractical.

A much simpler solution was suggested by Ferney Muñoz during the 17a Sesión de Tes@s en Wi-Fi when I gave a small presentation: if the APs are placed on the ceiling at the same height and the auditorium seat rows are stepped, just reduce the AP height accordingly from front to back. In other words, simulate an inclined floor using the APs instead of the floors.

Conclusion:

  • The floor plan sandwich technique is fun and provides detailed simulation of complex building artifacts…
  • …but it’s probably terrible for surveys.
  • The software limits the minimum ceiling height to 1m.
  • Simulated APs can be placed at any height, regardless of upper floors.
  • RF signal prediction is done at 1m height from the floor, customizable.
  • Enable signal prediction to all floors in order to see how an AP impacts the whole 3D model.
Legal note: Ekahau and Ekahau Pro are registered trademarks of Ekahau OY.
Categories
design

The sliding requirements

I am doing a project for a library warehouse with compact sliding shelves. It’s a large area in the basement with rows of metal bookshelves.

Every shelf is fitted on rails and has a crank that allows sliding an entire row left and right. Once the chosen shelf has been opened wide, a librarian can access the books inside and start working.

It’s basically a warehouse with moving aisles.

During the initial engagement phonecall I asked what the needs for wi-fi were, what type and how many devices had to connect, physical access procedures, security issues. I like to study the floorplans beforehand and prepare an Ekahau project with just the correct scale set, and nothing else.

A sector of the library warehouse.

I usually call the first site visit “the photoshoot”: while the contact person guides me around the premises, I ask questions and take pictures. Later I will return, taking measures, usually alone, but the photoshoot is focused on getting the most from my guide’s time.

I use the “stream of consciousness” photographic method: starting from the main entrance, I document the journey in the building every 3-4 m, at every turn, stair, door, floor sign or fire escape plan. I like to have pictures of the ceiling, cabling, MDF, outstanding furniture. Later at the office it will be easy to review the picture stream and compare it to my memory of the journey. Months after the visit, when you ask yourself “What was the ceiling like in room 1505?” this method allows me to find the right information among hundreds of pictures.

My contact person walked me around the library warehouse and kindly answered my questions. The whole warehouse is located underground and is quite big. It has just one landline phone, no cellphone coverage, some weak wifi signal leaking from the floor above. I helped my guide express her use cases in this way:

  • A a librarian, I need to use the laptop to access the database while I am doing work inside the compactus aisles.
  • As a supervisor, I need a simple communication channel for colleagues in case of need while in the warehouse.

This translates in basic connectivity for web access from laptops, and chat apps on mobile devices.

The next step at the office was to develop the predictive project, defining areas, requirements, walls and attenuation areas. I created a custom attenuation object for the compact racks, 2.5m high and 27dB/m. My reasoning is that the sturdy metal shelves and the material inside will totally block any wifi signal.

Coverage areas, walls, attenuation areas, simulated APs

This project will focus on coverage for low density areas, with simple 2×2:2 ac Extreme Networks 3915 APs .

The predictive signal from an AP placed on the ceiling 1m above the compact shelving does not travel very far down the aisles. In the picture below a simulated AP is placed at 3.5m height, the shelves are 2.5m high. Please note that the default predictive signal in Ekahau is simulated at 1m above the floor.

Predictive signal strength on 5Ghz at 14 dBm (18dBm EIRP)

Predictive design in Ekahau simulates the signal attenuation caused by free space path loss and wall/obstacle attenuation. It does not factor in reflection and other complex RF propagation effects. But here the environment is very complex: on the ceiling there are metal conduits, cabling trays, concrete rafters, low-ceiling areas and shelves of different size and model.

To validate the predictive design with actual measurements on site, let’s do an AP on a stick survey! I gathered my survey gear and headed to the library. After placing the APOS in a specific position I walked in a sliding aisle every 4 racks measuring the signal with the Sidekick. This time I was on my own, al the doors were open and the area was freely accessible and very quiet. I really enjoyed the time spent most productively there.

Placing an AP in the same position as the simulated AP above gave very encouraging results. The signal is pretty good inside the shelves, even far away from the AP.

5Ghz at 12 dBm (16 dBm EIRP), as measured

Adding a small offset to the measured data still shows decent coverage in awkward locations. The AP could be moved to a more central position, or the EIRP increased slightly.

5Ghz at 12 dBm (16 dBm EIRP), viewed as generic laptop -3dB

Even the notorious mobile device offset (around -10 dB) shows a workable coverage. Clients in the gray areas may choose 2.4 Ghz, the EIRP could be increased, or there would be just low RSSI and basic data rates.

5Ghz at 12 dBm (16 dBm EIRP), viewed as mobile device -10dB

The difference in the results from predictive design and from APOS can be explained perhaps as an excessive attenuation value in the predictive model. My personal view however is that multipath has an important role in that complex environment.

Based on the results on the field, I designed the whole library warehouse using a reasonable number of APs. The project is underway and I will share the validation results once it’s installed.

Categories
tools

Build your own wi-fi stand

I built my own wi-fi stand with 7€ worth of hardware store supplies. It fits nicely to my 30€ nondescript tripod for my AP on a stick surveys.

It’s basically a 1000mmx25mmx1mm steel strip, bent in a rectangle and bolted fast to an iron plate. It is slightly wider than the usual 23.8mm (15/16″) ceiling rail.

In horizontal mount position, heavier APs like this Extreme Networks 3935 are a bit wobbly, but stable nonetheless.

The vertical position is done rotating the mount and attaching the AP sideways.

I can even fit an outdoor AP 3965 with its heavy mounting plate.

I simply hang the outdoor AP 3965 using the mounting plate and the pole mount straps. I insert the stand above for safety reasons, and use work gloves for handling the AP because of the pole-mount sharp edges.

This wifi stand may not be stylish or refined, but it’s very practical!

Categories
CWNP

NAV and foreign STAs

The Sybex CWAP 2011 study guide contains a gem regarding how different BSSs interact:

[with the exception of transmitter and receiver,] Any other client or AP stations within hearing range on the same channel will reset their NAV, even if they are nont members of the BSS.

Chapter 3 review questions, q.10, answer p.120

It is the first time I find it clearly stated that STAs contending through HCF or EDCA will abide to any information they can decode from received frames, regardless if they are from the same BSS or not.

This makes sense, because:

  • APs know the AID of the members of it’s BSS, but client STA don’t;
  • any STA (AP or client) does physical carrier sense SD when it decodes a preamble, and it is likely to also decode the header which contains a length field which is the time it will take to transmit the frame (in microsecs);
  • Therefore it’s logical to use a NAV if it can decode it.

Perhaps this should be put in the CWNA study guide explicitly.

Categories
CWNP

Passed CWSP certification!

Today I took the CWSP exam and passed it with 90%. It’s exactly one year after I passed CWNA and the satisfaction and sense of accomplishment is great. The original plan was to study during winter and spring 2020 in order to take the exam in April. Then the COVID19 pandemic hit and changed all our priorities.

The current exam was CWSP-206, which has an official study guide from Certitrek (authored by Badman, Bartz, Carpenter, Hill, Morgan) and an almost updated (CWSP-205) study guide from Sybex (authored by Coleman, Westcott, Harkins).

A great guide by David Coleman, David Westcott and Bryan Harkins

It’s good to study both books: the Sybex is a high quality reference guide to understand our work, and the Certitrek a more exam-oriented tool with great content, but somewhat poor editorial depth (e.g. no chapter/section navigation, no index).

How to pass an exam and have fun with Kali Linux

I did not practice or setup a lab specifically for this exam, as most of my day to day work already touched most of the topics. Keeping up to date with blogs, Twitter and webinars was very useful, see my Twitter profile @MonorailHandles for my followed profiles which are almost all wi-fi related.

The CWNP practice tests were very useful to gauge my level of readiness and study the finishing touch. As with CWNA, the pass threshold is 70% and having scored 90% in the exam means I overstudied and delayed: chalk it up to an astonishing year with a pandemic, african locusts swooped over Milano by high altitude winds, and an earthquake near home.

Pearson Vue’s online proctored exam worked smoothly, I sat in an empty room at my office and the absolutely bare space may have helped the experience. It’s a good alternative to the physical exam center, in both convenience and comfort.

Now to the next thing: the original plan was CWDP, but my interests and professional curiosity drive me towards CWAP. Let’s see in the next weeks.

Categories
field notes

bikewifi device cooling

Early Aygust I was surveying one of the university buildings in Milano with my colleague. A heatwave was underway with outside temperatures of 35°C and in-building 30°C. We moved by bike, carrying survey kit and spare APs in my bike bags.

The building itself is interesting: a former cinema belonging to the nearby church, later rented by our university, the cinema transformed into a 200-seat lecture hall, the above floors offices. The view on the nearby XVI century church and art-nouveau buildings is wonderful.

We spent the morning surveying the building. Most of the time was used picking keys from a huge keyring and opening offices – then closing them again. After a couple of hours the tethered survey device was really hot and I didn’t want to stuff it back in the bag, even if it was turned off. So I found a creative solution:

Categories
field notes

How I learned to stop worrying and love all 5Ghz channels

Using all 5 Ghz channels available in your regulatory domain is not a choice, it’s a matter of fact. Here’s my experience.

I did a validation survey at one of our remote sites. The survey data showed severe co-channel interference almost everywhere. The site lies in open countryside and has no detectable neighboring APs: all of the APs are our own and they all transmit in the same 4 non-DFS channels as shown in the reading taken at location A on site:

The original situation at location A
Categories
tools

My Ekahau license expired during a survey

…and it took 9 days to restore it.

Two weeks ago I was doing a survey with the iPad, when my Ekahau license was suddenly suspended. I was logged out of the Survey for iPad app and lost access to all my cloud files. After 9 days the license was restored, and all has been well since. Here is my experience and lessons learned.

Categories
tools

Firts steps with Ekahau Survey for iPad

A couple of weeks ago I upgraded to Ekahau Connect and an iPad Pro for my RF surveys. I’ll write my first-hand experiences learning to use it and doing actual work.

Bottom line: get Connect and an ARK-enabled Apple device if you need to speed-up survey operations and if you (or your employer) can afford the price.

Categories
operations

Lessons from legacy 802.11n access points

Some Enterasys AP3600 ready for retirement

My colleague and I are finally completing the retirement of a legacy 802.11n deployment based on Enterasys AP3600s.

It was our university first modern wi-fi network back in 2010, based on modern hardware and latest technology (802.11n was released in 2009). In the following years a few hundred AP3600s were installed on the campus and provided the bulk of our WLAN access.
